Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They make equipment like boom lifts, aerial lifts and manlifts. These equipments are designed to facilitate access to places which are difficult to reach, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains handholds or platforms or steps which are connected to the unit in order to transport personnel from every floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall measures at 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
